IIoT System Enclosure

Overview

Syscor’s IIoT System Enclosure is a rapidly deployable solution to establish a local WirelessHART network and contains monitoring software that collects and interprets field device data. Information can be transmitted to the site’s existing SCADA and/or viewed via a cloud application. The IIoT box can contain a cellular modem for installations that lack communication infrastructure.

Applications:

Primarily WirelessHART field devices monitoring petroleum infrastructure.

Highlights

Enables easy scaling of WirelessHART field devices
Syscor Tracker Monitoring Software can be accessed through an IIoT cloud or by directly plugging an ethernet cable to the unit
Doorstrike monitoring of open/close events and provision for padlock
Antennas are remotely mounted with a cable to offer precise positioning
Operating temperature: -40°C to +70°C [-40 °F to +158 °F]
Approximately 33.8 kg (74.5lbs)
Dimensions LxWxH: 500mm (20”) x 203.2mm (8”) x 641.35mm (25.25”)

Network Topology

Enclosure Network

Accessories

Standard enclosure mounting hardware is available (struts)
Comes with omni-directional 8dBi gateway antenna and 6dBi cellular antenna (mounting brackets included); optional lightning arrestors are available

Documents

PDF IIoT System Enclosure Solution Sheet

Learn more

WirelessHART
